Diagnostic > CX20N

CX20N

2M

Diagnostic Color Display

  • 14-bit Look-Up Table
  • Embedded IQ Sensor®
  • PrivateLite®
  • DisplayPort & DVI
  • Specifications
  • Graphics Cards
Model CX20N
LCD Panel TFT AMLCD IPS Color
Native Resolution 1600 x 1200 @ 60Hz
Pixel Pitch 0.270mm x 0.270mm
Active Display Area 432.0mm x 324.0mm (17.0”x12.8”)
Active Screen Size (Diagonal) 540.0mm (21.3”)
Viewing Angle (Typ) 178º,178º at 10:1 Contrast Ratio
Brightness Max. (Typ) 1000cd/m²
Brightness Calibrated (Typ) 450cd/m²
Contrast Ratio (Typ) 1800:1
Bit Rate for Look-Up Table 14-bit
Digital Video Input DVI-I, DisplayPort
Display Communication DDC2B (VESA Standard Compliance)
Universal Serial Bus (USB) 1 up and 3 down-streams
Power Supply AC Input: 100-240Volt±10% / 60Hz/50Hz±3Hz | DC Output: +24V
Built-in Sensors IQ Sensor III®, SBC, DAC
Luminance Uniformity Control (LUC) Yes
Display Adjusstments Menu, Enter, Down, Up, Lamp, Power
OSD Languages English, German, French, Spanish, Italian, Russian, Japanese, Chinese, Korean
LED Lignt (PrivateLite®) Yes
Power Consumpiton Max: 60W, Power Save: 2W
Tilt/Swivel/Height Adjustments -3º,+15º/±20º/110mm
Pprtrait/Landscape Rotation 90º (Counter clockwise)
Mountiong Hole VESA Standard (100mmx100mm)
Weight 9.3Kg(20.50lb) with Stand
Dimension 366.0mm(W)x518.8mm(H)x248.8mm(D)
Operational Temperature 0ºC to 40ºC (32ºF to 104ºF)
Operational Humidity 8% to 80%
Storage Temperature -20ºC to 60ºC (-4ºF to 140ºF)
Certifications and Standards ANSI/AAMI ES 60601-1, EN60601-1, IEC60601-1, CE, VCCI, KC, C-Tick, FCC
Options Protective Glass
Model Name OS System Supported Frame Buffer Memory Bus Interface Max Resolution Output

RadeonPro WX3100

Windows 7-64-bit , Windows 10-64-bit 4GB PCI Express 3.0 5120 x 2880 DisplayPort x 1 , Mini DisplayPort x 2

Quadro P4000

Windows 7 , Windows 8.1 , Windows 10 8GB PCI Express 3.0 4096 x 2160 DisplayPort x 4

Quadro P2000

Windows 7 , Windows 8.1 , Windows 10 5GB PCI Express 3.0 5120 x 2880 DisplayPort x 4

Quadro T1000

Windows 7 , Windows 8.1 , Windows 10 4GB PCI Express 3.0 7680 X4320 Mini DisplayPort x 4

RadeonPro WX7100

Windows 7-64-bit , Windows 10-64-bit 8GB PCI Express 3.0 5120 x 2880 DisplayPort x 4

RadeonPro WX5100

Windows 7-64-bit , Windows 10-64-bit 8GB PCI Express 3.0 5120 x 2880 DisplayPort x 4

Radeon RX6800

Windows 7 , Windows 10 8GB PCI Express 4.0 7680 x 4320 HDMI x 2 , DisplayPort x 2

GeForce GTX1660Ti

Windows 7 , Windows 8.1 , Windows 10 6GB PCI Express 3.0 7680 x 4320 HDMI x 1 , DisplayPort x 3

GeForce RTX3080

Windows 7 , Windows 10 10GB PCI Express 4.0 7680 x 4320 HDMI x 2 , DisplayPort x 3

Quadro RTX4000

Windows 7 , Windows 8.1 , Windows 10 8GB PCI Express 3.0 7680 x 4320 USB Type-C x 1 , HDMI x 1 , DisplayPort x 3

Quadro P2200

Windows 7 , Windows 8.1 , Windows 10 5GB PCI Express 3.0 5120 x 2880 DisplayPort x 4

RadeonPro WX3100

OS System Supported Windows 7-64-bit , Windows 10-64-bit
Frame Buffer Memory 4GB
Bus Interface PCI Express 3.0
Max Resolution 5120 x 2880
Output DisplayPort x 1 , Mini DisplayPort x 2

Quadro P4000

OS System Supported Windows 7 , Windows 8.1 , Windows 10
Frame Buffer Memory 8GB
Bus Interface PCI Express 3.0
Max Resolution 4096 x 2160
Output DisplayPort x 4

Quadro P2000

OS System Supported Windows 7 , Windows 8.1 , Windows 10
Frame Buffer Memory 5GB
Bus Interface PCI Express 3.0
Max Resolution 5120 x 2880
Output DisplayPort x 4

Quadro T1000

OS System Supported Windows 7 , Windows 8.1 , Windows 10
Frame Buffer Memory 4GB
Bus Interface PCI Express 3.0
Max Resolution 7680 X4320
Output Mini DisplayPort x 4

RadeonPro WX7100

OS System Supported Windows 7-64-bit , Windows 10-64-bit
Frame Buffer Memory 8GB
Bus Interface PCI Express 3.0
Max Resolution 5120 x 2880
Output DisplayPort x 4

RadeonPro WX5100

OS System Supported Windows 7-64-bit , Windows 10-64-bit
Frame Buffer Memory 8GB
Bus Interface PCI Express 3.0
Max Resolution 5120 x 2880
Output DisplayPort x 4

Radeon RX6800

OS System Supported Windows 7 , Windows 10
Frame Buffer Memory 8GB
Bus Interface PCI Express 4.0
Max Resolution 7680 x 4320
Output HDMI x 2 , DisplayPort x 2

GeForce GTX1660Ti

OS System Supported Windows 7 , Windows 8.1 , Windows 10
Frame Buffer Memory 6GB
Bus Interface PCI Express 3.0
Max Resolution 7680 x 4320
Output HDMI x 1 , DisplayPort x 3

GeForce RTX3080

OS System Supported Windows 7 , Windows 10
Frame Buffer Memory 10GB
Bus Interface PCI Express 4.0
Max Resolution 7680 x 4320
Output HDMI x 2 , DisplayPort x 3

Quadro RTX4000

OS System Supported Windows 7 , Windows 8.1 , Windows 10
Frame Buffer Memory 8GB
Bus Interface PCI Express 3.0
Max Resolution 7680 x 4320
Output USB Type-C x 1 , HDMI x 1 , DisplayPort x 3

Quadro P2200

OS System Supported Windows 7 , Windows 8.1 , Windows 10
Frame Buffer Memory 5GB
Bus Interface PCI Express 3.0
Max Resolution 5120 x 2880
Output DisplayPort x 4
